Dimensions
| Nominal cross-section |
Overall diameter (Approx) |
Net Weight (Approx) |
Delivery Lenght |
Conductor DC Resistance |
Current carrying capacity in | |
| mm² | mm | kg/km | m | ohm/km | In conduit at 20°C A | In air at 30°C A |
| 2×1,5 | 8,8 | 112 | 100 | 12,1 | – | 18 |
| 2×2,5 | 10 | 153 | 100 | 7,41 | – | 26 |
| 2×4 | 11 | 200 | 100 | 4,61 | – | 34 |
| 2×6 | 12 | 256 | 100 | 3,08 | – | 44 |
| 2×10 | 15,2 | 418 | 1000 | 1,83 | – | 61 |
| 2×16 | 17 | 576 | 1000 | 1,15 | – | 82 |
| 2×25 | 21,5 | 970 | 1000 | 0,727 | – | 108 |
| 2×35 | 24,5 | 1280 | 1000 | 0,524 | – | 135 |
| 3×1,5 | 9,2 | 131 | 100 | 12,1 | – | 18 |
| 3×2,5 | 10,5 | 182 | 100 | 7,41 | – | 26 |
| 3×4 | 11,6 | 243 | 100 | 4,61 | – | 34 |
| 3×6 | 13,1 | 329 | 100 | 3,08 | – | 44 |
| 3×10 | 16 | 519 | 1000 | 1,83 | – | 61 |
| 3×16 | 18,4 | 753 | 1000 | 1,15 | – | 82 |
| 3×25 | 19,5 | 820 | 1000 | 0,727 | – | 108 |
| 3×35 | 23,1 | 1230 | 1000 | 0,524 | – | 135 |
| 4×1,5 | 9,9 | 157 | 100 | 12,1 | – | 18 |
| 4×2,5 | 11,4 | 223 | 100 | 7,41 | – | 26 |
| 4×4 | 13 | 311 | 100 | 4,61 | – | 34 |
| 4×6 | 14,6 | 423 | 100 | 3,08 | – | 44 |
| 4×10 | 17,5 | 649 | 1000 | 1,83 | – | 61 |
| 4×16 | 20,1 | 942 | 1000 | 1,15 | – | 82 |
| 4×25 | 26 | 1540 | 1000 | 0,727 | – | 108 |
| 4×35 | 28,5 | 1990 | 1000 | 0,524 | – | 135 |
| 5×1,5 | 10,8 | 188 | 100 | 12,1 | – | 18 |
| 5×2,5 | 12,4 | 268 | 100 | 7,41 | – | 26 |
| 5×4 | 14,5 | 390 | 100 | 4,61 | – | 34 |
| 5×6 | 15,9 | 512 | 100 | 3,08 | – | 44 |
| 5×10 | 19,1 | 792 | 1000 | 1,83 | – | 61 |
| 5×16 | 22,4 | 1173 | 1000 | 1,15 | – | 82 |
| 5×25 | 28 | 1840 | 1000 | 0,727 | – | 108 |
| 5×35 | 31,5 | 2425 | 1000 | 0,524 | – | 135 |
